Durkopp Adler 869-280322-M

M-TYPE 869-M CLASSIC Goldline - twin needle cylinder arm machine with vertical hooks

Field of application:

Functional seams and decorative seams in tubular workpieces

Performance features:

• Thread sizes up to max. Tkt. 10/3
• Max. stitch length 9 mm
• Max. sewing speed 2,800 stitches/min.
• Needle distances up to 30 mm max.

Overview:

• Integrated direct drive with networkable "DAC classic" control incl. operating panel OP1000 - Industry 4.0 "ready"
• The high sewing foot lift facilitates the feeding and removal of bulky workpieces
• Hook technology allows the processing of extremely thick sewing thread sizes up to max. Tkt. 10/3
• Solid thread trimmer with a remaining thread length of 15 mm only
• Excellent stitch pattern, constantly tight stitch for­mation, even with large stitch lengths and extreme thread sizes
• Safety clutch protects against hook damage
• The high top feed stroke facilitates sewing over thick spots
• Equipment features corresponding to the M-TYPE CLASSIC version like thread trimmer, auto­matic backtacking, pneumatic sewing foot lift, inte­ grated LED sewing lamp and maintenance indicator
• Also available as ECO version (869-280020-M)
